Vacuum Dehumidifying Dryer
The Vacuum Dehumidifying Dryer is designed to meet the "green dry" idea of dehumidifier for plastic materials.
The vacuum dehumidifying dryer takes much shorter time on drying plastic pellets.
It's the most efficient, and energy-saving dryer amount plastic granules dryers for hygroscopic materials.
PLC controls the accurate amount and time of pre-heating and vacuum drying, ensure the best and efficient time of drying.
FEATURE
- The material preheating system uses hot air recycling and insulation designed to meet the" green dry" idea.
- Vacuum dehumidification system uses the design of vacuum degree below 1 Torr. Water evaporation temperature can be reduced to below room temperature, and be able to achieve rapid drying purposes.
- Material conveying system with vacuum dehumidification system share the same power source.
- Lead drying time has shortened more than half than adsorption dehumidifying system.
- Energy saving compared to adsorption dehumidifying system has saving more than 30% of the electricity demand.
- Equipped with Heaterless Dryer in the Buffer tank for preventing material moisture again.
- PLC and colorful human-machine screen for simple operating and monitoring easily.
KVD Comparison & Energy Comsumption Analysis
Specifications
|
Type |
Vacuum Dehumidifying Dryer |
Dehumidifying Dryer |
|
|---|---|---|---|
|
Dehumidifying |
Dehumidifying method |
Vacuum |
Adsorption |
|
Desiccant rotor andmolecular sieve cylinder |
None |
Need |
|
|
Drying barrel |
Small Capacity |
Large Capacity |
|
|
Drying heater |
Low Power |
High Power |
|
|
Drying blower |
Low Power |
High Power |
|
|
Hot air recycle |
Direct recycle |
Recycle after cooling |
|
|
Regeneration |
Regenerative heater |
None |
Need |
|
Regenerative blower |
None |
Need |
|
|
Cooling |
Vacuum motor |
Need |
None |
|
Drying blower |
None |
Need |
|
|
Lead time |
1~2 hours |
4~6 hours |
|
|
Space occupied |
Smaller |
Bigger |
|
|
Energy saving |
Saving more than 30% |
More electricity expense |
|
|
Type |
Vacuum Dehumidifying Dryer |
Dehumidifying Dryer |
|
|---|---|---|---|
|
Model |
KVD-200 |
KRD-800-3 |
|
|
Total load |
41.1KW |
61.9KW |
|
|
Power consumption |
Total load |
0.205 KW/KG、HR |
0.310 KG/KG、HR |
|
Estimate 70% of total load |
0.143 KW/KG、HR |
0.217 KW/KG、HR |
|
|
Comparison rate |
66.39% |
100% |
|
|
Power saving rate |
33.61% |
- |
|
|
Power saving |
Hour (1 Hour) |
15KW |
- |
|
Day (24 Hours) |
360KW |
- |
|
|
Month (25 Days) |
9,000KW |
- |
|
|
Year (300 Days) |
108,000KW |
- |
|
|
Electricity expense saving |
Hour (1 Hour) |
US$2.3 |
- |
|
Day (24 Hours) |
US$55 |
- |
|
|
Month (25 Days) |
US$1,375 |
- |
|
|
Year (300 Days) |
US$16,500 |
- |
|
|
Model |
KVD-12 |
KVD-25 |
KVD-50 |
KVD-75 |
||
|---|---|---|---|---|---|---|
|
Capacity |
KG/HR |
12 |
25 |
50 |
75 |
|
|
Drying barrel |
KG |
25 |
50 |
100 |
150 |
|
|
Vacuum barrel |
KG |
4 |
8 |
16 |
25 |
|
|
Buffer tank |
KG |
12 |
25 |
50 |
75 |
|
|
Drying heater |
Drying barrel |
KW |
6.50 |
6.50 |
12.00 |
12.00 |
|
Drying blower |
60HZ |
KW |
0.85 |
0.85 |
1.90 |
1.90 |
|
50HZ |
0.75 |
0.75 |
1.75 |
1.75 |
||
|
Vacuum motor |
60HZ |
KW |
1.20 |
1.20 |
1.20 |
1.20 |
|
50HZ |
1.00 |
1.00 |
1.00 |
1.00 |
||
|
Central loader |
60HZ |
KW |
0.85 |
0.85 |
0.85 |
1.90 |
|
50HZ |
0.75 |
0.75 |
0.75 |
1.75 |
||
|
Central material receiver |
3LITER (KCMR-3W) *2PCS |
6LITER (KCMR-6W) *2PCS |
||||
|
Control type |
7.7" Colorful human-machine touch panel and PLC controller |
|||||
|
Compressed air |
MM |
ø5*8MM at 5~7KG/CM² |
||||
|
LPM |
100 |
100 |
200 |
200 |
||
|
Total load |
60HZ |
KW |
9.40 |
9.40 |
15.90 |
17.00 |
|
50HZ |
9.00 |
9.00 |
15.50 |
16.50 |
||
|
Dimension |
Machine (CM) |
W |
105 |
105 |
115 |
115 |
|
D |
180 |
180 |
200 |
200 |
||
|
H |
300 |
300 |
310 |
310 |
||
|
Approx. weight |
KG |
750 |
800 |
900 |
950 |
|
|
Options |
1. PVC Spring hose 2. Suction probe |
|||||
|
Remarks |
1.We reserve the right to change specifications without prior notice. |
|||||
|
Model |
KVD-100 |
KVD-150 |
KVD-200 |
KVD-250 |
||
|---|---|---|---|---|---|---|
|
Capacity |
KG/HR |
100 |
150 |
200 |
250 |
|
|
Drying barrel |
KG |
200 |
300 |
400 |
500 |
|
|
Vacuum barrel |
KG |
33 |
50 |
66 |
83 |
|
|
Buffer tank |
KG |
100 |
150 |
200 |
250 |
|
|
Drying heater |
Drying barrel |
KW |
18.0 |
18.0 |
24 |
24 |
|
Drying blower |
60HZ |
KW |
3.70 |
3.70 |
6.30 |
6.30 |
|
50HZ |
3.40 |
3.40 |
5.50 |
5.50 |
||
|
Vacuum motor |
60HZ |
KW |
1.70 |
1.70 |
2.40 |
3.40 |
|
50HZ |
1.40 |
1.40 |
2.00 |
2.70 |
||
|
Central loader |
60HZ |
KW |
1.90 |
1.90 |
1.90 |
2.60 |
|
50HZ |
1.75 |
1.75 |
1.75 |
2.20 |
||
|
Central material receiver |
15LITER (KCMR-15W) *2PCS |
|||||
|
Control type |
7.7" Colorful human-machine touch panel and PLC controller |
|||||
|
Compressed air |
MM |
ø5*8MM at 5~7KG/CM² |
||||
|
LPM |
300 |
300 |
400 |
400 |
||
|
Total load |
60HZ |
KW |
25.30 | 25.30 |
34.60 |
36.30 |
|
50HZ |
24.55 |
24.55 |
33.25 |
34.40 |
||
|
Dimension |
Machine (CM) |
W |
115 |
135 |
135 |
145 |
|
D |
200 |
245 |
270 |
280 |
||
|
H |
320 |
355 |
355 |
420 |
||
|
Approx. weight |
KG |
1100 |
1200 |
1600 |
2000 |
|
|
Options |
1. PVC Spring hose 2. Suction probe |
|||||
|
Remarks |
1.We reserve the right to change specifications without prior notice. |
|||||
